Name: Putco Luminix™ Off-Road LED Light Bar
Brand: Putco
SKU: Luminix-LED-Light-Bar
Availability: InStock

Features

Super Bright Off-road Lights: 50,000-hour LED bulb life. 6000K color temperature.
Superior Performance: 15-degree focus lenses with output from 1,200LM to 27,600LM.
Light Bar Options: 6″ to 70″ in straight and curved designs with 3-watt LEDs.
Matte Black Billet Anodized Aluminum: Crafted with a sealed, anodized aluminum that is protected with a UV-protected matte black finish.
Powerful Offroad Lighting: 12 Volts, NICHIA LEDs to accomplish high LUMEN output with 3 Watts per LED & only a .75 amps draw per LED.
Off-Road Rated Light Bar: IP69K rated for dust and moisture protection, ensuring years of reliable use. Operating temperature (Equal or greater than -100 Degrees F to 180 Degrees F.
Argon Injected LED Housing: Zero moisture ingression, superior thermal insulation barrier, eliminates corrosion & non-reactive to other elements.
Warranty: Industry-leading 3-year warranty.
Designed and manufactured in the USA: Designed by Putco Inc., Des Moines, IA.

Putco’s Luminix™ Off-Road LED Light Bar is designed & engineered for 15-degree focus lenses, offering output ranging from 1,200LM to 27,600LM for off-road lighting use. It is built to handle the elements of all your adventures and create a super-bright LED beam pattern. These off-road LED light bars for trucks, side-by-sides, trailers, and more are powered by 12 volts, but can also operate on 24 volts and 36 volts.

The housing is made of anodized matte black billet aluminum with a UV-protected anodized finish, ensuring durability and maintaining its great looks for years to come. This LED light bar can withstand the bumps, jars, and pounding your truck experiences on and off-road, and still function under extreme conditions. The Luminix™ Off-Road LED Light Bars are rated at 400 lumens per LED output and feature a 6000 K color temperature for the ultimate off-road lighting experience. They have been vibration tested, as well as subjected to dust, immersion, high spray water, salt, and fog, to ensure superior performance. Designed by Putco Inc., Des Moines, IA.

California Residents: Proposition 65 Warning

Video

Putco Luminix LED Light Bar Video

Specs

Putco Luminix LED Light Bar Specifications

SKU	Type	Bulb Type	Bulb Color	Lumens	Kelvin Scale
PUT-10010	Luminix High Power LED – 10″ Light Bar – 9 LED – 3,600LM – 11.64x.75×1.5 – Inches.	LED	White	3600	6000K
PUT-10020	Luminix High Power LED – 20″ Light Bar – 18 LED – 7,200LM – 21.63x.75×1.5 – Inches.	LED	White	7200	6000K
PUT-10033	Luminix High Power LED – 30″ Curved Light Bar – 27 LED – 10,800LM – 31.63x.75×1.5 – Inches – 6 Degrees.	LED	White	10800	6000K
PUT-10030	Luminix High Power LED – 30″ Light Bar – 27 LED – 10,800LM – 31.63x.75×1.5 – Inches.	LED	White	10800	6000K
PUT-10046	Luminix High Power LED – 40″ Curved Light Bar – 39 LED – 15,600LM – 41.63x.75×1.5 – Inches – 6 degrees.	LED	White	15600	6000K
PUT-10040	Luminix High Power LED – 40″ Light Bar – 39 LED – 15,600LM – 41.63x.75×1.5 – Inches.	LED	White	15600	6000K
PUT-10055	Luminix High Power LED – 50″ Curved Light Bar – 48 LED – 19,200LM – 51.63x.75×1.5 – Inches – 6 Degrees.	LED	White	19200	6000K
PUT-10050	Luminix High Power LED – 50″ Light Bar – 48 LED – 19,200LM – 51.63x.75×1.5 – Inches.	LED	White	19200	6000K
PUT-10006	Luminix High Power LED – 6″ LIGHT BAR – 3 LED – 1,200LM – 5x.75×1.5 – Inches.	LED	White	1200	6000K
PUT-10063	Luminix High Power LED – 60″ Curved Light Bar – 57 LED – 22,800LM – 61.63x.75×1.5 – Inches – 6 degrees.	LED	White	22800	6000K
PUT-10060	Luminix High Power LED – 60″ Light Bar – 57 LED – 22,800LM – 61.63x.75×1.5 – Inches.	LED	White	22800	6000K
PUT-10070	Luminix High Power LED – 70″ Light Bar – 69 LED – 27,600LM – 71.63x.75×1.5 – Inches.	LED	White	27600	6000K

Install

Putco Luminix led light bar is fairly straight forward to install with Putco step by step instructions and included hardware. However, 12 volt light wiring experience is helpful.
